WHERE LEGENDARY RELIABILITY MEETS CUTTING EDGE PERFORMANCE

Superseding the ever-popular DF115A and DF140A outboard motors, the new “B” series feature a host of updates, many of which are shared with the highly acclaimed DF115BG, and DF140BG Suzuki Precision Control (SPC) drive-by-wire outboard motors released in 2021, albeit in mechanically driven form.

Specifications

Discover More
Recommended Transom Height (mm)L: 508mm, X: 635mm
Weight (Kg*)L: 188kg, X: 192kg
Engine TypeIn-line 4
Piston Displacement (cm³)2,045cm³
Maximum Output (kw)84.6kW
Steering-
Recommended FuelRON91 / AKI87
Alternator12V 40A
Gear Ratio2.59 : 1 (Two-stage gear reduction)
ExhaustThrough Prop Hub Exhaust
Starting SystemElectric
Cylinders-
Fuel Delivery SystemElectronic Fuel Injection
Bore x Stroke (mm)86 x 88mm
Full Throttle Operating Range (rpm)5,000 - 6,000rpm
Oil Pan Capacity (L)5.5L
Fuel Tank Capacity (L)-
Trim MethodPower Trim and Tilt
Gear ShiftF-N-R
Propeller Selection (Pitch)15” - 25” (R/R), 17” - 23” (C/R)
