Compact, lightweight and fuel-efficient.

Compact, lightweight and fuel-efficient.

Tiller model
The DF60ATHL is a powerful, quick and efficient outboard and has the largest reduction gear ratio in its class.

Discover Suzuki's 3+3 year Warranty for recreational used outboards, plus other terms and conditions for commercial and government registered outboards under Suzuki's Warranty Policy.
DF60 TILLER OUTBOARD

Features

Specifications

Discover More
Recommended Transom Height (mm)S: 381, L: 508. X: 635*3
Weight (Kg*)S: 102, L: 104, X: 107*3
Valve Train -
Displacement (cm³)941
Maximum Output (kw)44.1
Control System-
Recommended FuelRON91 / AKI87
Alternator12V 19A
Gear Ratio2.27 : 1
ExhaustThrough Prop Hub Exhaust
Engine Mounting-
Starting SystemElectric
Engine TypeDOHC 12-Valve
CylindersIn-line 3
Fuel Delivery SystemElectronic Fuel Injection
Bore x Stroke (mm)72.5 x 76
Full Throttle Operating Range (rpm)5,300 - 6,300
Oil Pan Capacity (L)2.7
Fuel Tank Capacity (L)Separate (optional) 25
Trim MethodPower Trim and Tilt
Gear ShiftF-N-R
Propeller Selection (Pitch)9” - 17”
